HOW TO PROGRAM YOUR 425-1665 OPENER
HELP....What do I do?
Everything is installed but nothing works?
I programmed the remotes and still nothing?
Here is how to program your opener and make it work
Thinks to check first!!
  1. Install opener as specified in manual
  2. Performax photo eyes have been installed using supplied wiring
  3. Performax photo eyes are aligned page 14.
  4. Performax wall panel has been installed using supplied wiring page 15.
  5. Trolley is attached to garage door using door arms.
  6. Emergency release handle is engaged.
  7. Opener is plugged into a power source.
  8. Belt or chain tension has been set as recommended on page 7 of the manual.
  9. Performax wall panel is glosing dim red. (bright red if locked)
Placeholder image
  1. Go to the back of the opener as shown above
  1. Here are the buttons you will operate
FIRST: PROGRAM UP LIMIT (With the garage door in the CLOSED position)
Step 1:
Push/release the white limit button once.
Step 2:
The green up light will illuminate.
Step 3:
With the green up illuminated press and hold the green up button.
Step 4:
Garage door will travel up and trolley will move towards the opener. Take special care not to hit the stop bolt located in the rail.
Step 6:
Release green up button when door has reached the full open position.
Step 7:
You can micro adjust by pressing/releasing the up and down buttons
Step 8:
Push/release white limit once. Orange ok light will flash once.
Next Down Limit
Next step to programming is to set the down limit - go to next step 9
SECOND: PROGRAM DOWN LIMIT (With the garage door in the OPEN position)
Step 9:
Push/release the white limit button twice.
Step 10:
The red down light will illuminate.
Step 11:
With the red down illuminated press and hold the red down button.
Step 12:
Garage door will travel down and trolley will move away from the opener.
Step 13:
Release red down button when door has reached the full closed position.
Step 14:
You can micro adjust by pressing/releasing the up and down buttons
Step 15:
Push/release white limit once. Orange ok light will flash once.
Next Force
Next step to programming is to set force - go to next step 16
THIRD: PROGRAM FORCE (With the garage door in the CLOSED position)
Step 16:
Both of the green and red lights should be illuminated. Press/release the blue force button once.
Step 17:
The garage door will automatically trave all the way up and stop for a few seconds then reverse.
Step 18:
The garaged door will automatically travel all the way down and stop.
Step 19:
The orange light will flash and the unit will beep 3 times. Your are now done programming.
GREAT JOB!! YOUR OPENER IS NOW PROGRAMMED AND READY TO OPERATE!!
FOURTH: TEST YOUR OPENER (With the garage door in the CLOSED position)
Step 19:
Push/release the large white button on the wall button.
Step 20:
The garage door will travel up and stop at full open.
Step 21:
Push/release the large white button on the wall button.
Step 22:
The garage door will travel down and stop at full closed.
FIFTH: PROGRAM HANDHELD TRANSMITTERS / REMOTES
Step 23:
Push/release the yellow learn button once. Orange OK light will illuminate.
Step 24:
Press/release one of the three buttons on the remote.
Step 25:
OK light will flash and the opener will beep twice.
Step 26:
Press/release one of the three buttons on the remote. The garage door will open.
CONGRATULATIONS!! You have successfully programmed your opener!!
Still have questions please contact us here
